711433

antibody from Invitrogen Antibodies

Targeting: KLF17 FLJ40160, Zfp393, ZNF393

Western blot (Supportive data in Antibodypedia)

Immunocytochemistry (Supportive data in Antibodypedia)

Antibody Data

Product number

711433

Provider

Invitrogen Antibodies

Product name

KLF17 Recombinant Polyclonal Antibody (7HCLC)

Antibody type

Polyclonal

Antigen

Other

Description

This antibody is predicted to react with Monkey, Bovine and Sheep

Antibody clone number

7HCLC

Concentration

0.5 mg/mL

Western blot

Supportive validation

Submitted by

Invitrogen Antibodies (provider)

Main image

Experimental details

Western blot analysis was performed on Nuclear enriched extracts (30 µg lysate) of RAW 264.7 (Lane 1) and Tissue extracts of Mouse Testis (Lane 2) and Rat Testis (Lane 3). The blots were probed with Anti-KLF17 Recombinant Rabbit Polyclonal Antibody (Product # 711433, 1-2 µg/mL) and detected by chemiluminescence using Goat anti-Rabbit IgG (H+L) Superclonal Secondary Antibody, HRP conjugate (Product # A27036, 0.4 µg/mL, 1:2500 dilution). A 55 kDa band corresponding to KLF17 was observed across the cell lines and tissues tested. Known quantity of protein samples were electrophoresed using Novex®NuPAGE®4-12% Bis-Tris gel (Product # NP0321BOX), XCell SureLock Electrophoresis System (Product # EI0002) and Novex® Sharp Pre-Stained Protein Standard (Product # LC5800). Resolved proteins were then transferred onto a nitrocellulose membrane with iBlot® Dry Blotting System (Product # IB21001). The membrane was probed with the relevant primary and secondary Antibody following blocking with 5% skimmed milk. Chemiluminescent detection was performed using Pierce™ ECL Western blotting Substrate (Product # 32106).

Immunocytochemistry

Supportive validation

Submitted by

Invitrogen Antibodies (provider)

Main image

Experimental details

For immunofluorescence analysis, Hep G2 cells were fixed and permeabilized for detection of endogenous KLF17 using Anti- KLF17 Recombinant Rabbit Polyclonal Antibody (Product # 711433, 2 µg/mL) and labeled with Goat anti-Rabbit IgG (H+L) Superclonal Secondary Antibody, Alexa Fluor® 488 conjugate (Product # A27034, 1:2000). Panel a) shows representative cells that were stained for detection and localization of KLF17 protein (green), Panel b) is stained for nuclei (blue) using SlowFade® Gold Antifade Mountant with DAPI (Product # S36938). Panel c) represents cytoskeletal F-actin staining using Alexa Fluor® 555 Rhodamine Phalloidin (Product # R415, 1:300). Panel d) is a composite image of Panels a, b and c clearly demonstrating nuclear localization of KLF17. Panel e) represents control cells with no primary antibody to assess background. The images were captured at 60X magnification.
