PB9294

antibody from Boster Biological Technology

Targeting: NOD1 CARD4, CLR7.1, NLRC1

Western blot (Supportive data in Antibodypedia)

Immunocytochemistry (Data presented on provider website)

Immunohistochemistry (Data presented on provider website)

Antibody Data

Product number

PB9294

Provider

Boster Biological Technology

Product name

Anti-CARD4/NOD1 Antibody Picoband™

Antibody type

Polyclonal

Description

Polyclonal antibody for CARD4/NOD1 detection. Host: Rabbit.Size: 100μg/vial. Tested applications: IHC-P. Reactive species: Human. CARD4/NOD1 information: Molecular Weight: 107691 MW; Subcellular Localization: Cytoplasm. Cell membrane. Apical cell membrane. Basolateral cell membrane. Detected in the cytoplasm and at the cell membrane. Following bacterial infection, localizes to bacterial entry sites in the cell membrane. Recruited to the basolateral and apical membranes in polarized epithelial cells; Tissue Specificity: Highly expressed in adult heart, skeletal muscle, pancreas, spleen and ovary. Also detected in placenta, lung, liver, kidney, thymus, testis, small intestine and colon.

Reactivity

Human, Rat

Host

Rabbit

Vial size

100μg/vial

Concentration

Add 0.2ml of distilled water will yield a concentration of 500ug/ml.

Storage

At -20°C for one year. After reconstitution, at 4°C for one month. It can also be aliquoted and stored frozen at -20°C for a longer time. Avoid repeated freezing and thawing.

Handling

Add 0.2ml of distilled water will yield a concentration of 500ug/ml.

References

Submitted references

Nucleotide-binding oligomerization domain protein 1 enhances oxygen-glucose deprivation and reperfusion injury in cortical neurons via activation of endoplasmic reticulum stress-mediated autophagy.

Ma X, Zhang W, Xu C, Zhang S, Zhao J, Pan Q, Wang Z
Experimental and molecular pathology 2020 Dec;117:104525

Western blot

Supportive validation

Submitted by

Boster Biological Technology (provider)

Main image

Experimental details

Western blot analysis of CARD4 using anti-CARD4 antibody (PB9294). Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 50ug of sample under reducing conditions. Lane 1: A549 Whole Cell Lysate, Lane 2: Rat Cardiac Muscle Tissue Lysate. After Electrophoresis, proteins were transferred to a Nitrocellulose membrane at 150mA for 50-90 minutes. Blocked the membrane with 5% Non-fat Milk/ TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-CARD4 antigen affinity purified polyclonal antibody (Catalog # PB9294) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:10000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for CARD4 at approximately 107KD. The expected band size for CARD4 is at 107KD.

Additional image
