720311

antibody from Invitrogen Antibodies

Targeting: TPM4

Western blot (Supportive data in Antibodypedia)

Immunocytochemistry (Supportive data in Antibodypedia)

Antibody Data

Product number

720311

Provider

Invitrogen Antibodies

Product name

TPM4 Polyclonal Antibody

Antibody type

Polyclonal

Antigen

Synthetic peptide

Reactivity

Human, Mouse

Host

Rabbit

Isotype

IgG

Vial size

100 µg

Concentration

0.5 mg/mL

Storage

Store at 4°C short term. For long term storage, store at -20°C, avoiding freeze/thaw cycles.

Western blot

Supportive validation

Submitted by

Invitrogen Antibodies (provider)

Main image

Experimental details

Western blot analysis was performed on Whole cell extracts and tissue extracts (30 µg lysate) of A549 (Lane 1), HeLa (Lane 2), Jurkat (Lane 3), U-87 MG (Lane 4), A-431 (Lane 5), MCF-7 (Lane 6), MOLT4 (Lane 7), Mouse Ovary (Lane 8) and MDA-MB-231 (Lane 9). The blots were probed with Anti-TPM4 (Tropomyosin 4) Rabbit Polyclonal Antibody (Product # 720311, 1-2 µg/mL) and detected by chemiluminescence using Goat anti-Rabbit IgG (H+L) Superclonal Secondary Antibody, HRP conjugate (Product # A27036, 0.4 µg/mL, 1:2500 dilution). A 28 kDa band corresponding to TPM4 was observed across the cell lines and tissues tested. Known quantity of protein samples were electrophoresed using Novex®NuPAGE®4-12% Bis-Tris gel (Product # NP0321BOX), XCell SureLock Electrophoresis System (Product # EI0002) and Novex® Sharp Pre-Stained Protein Standard (Product # LC5800). Resolved proteins were then transferred onto a nitrocellulose membrane with iBlot® Dry Blotting System (Product # IB21001). The membrane was probed with the relevant primary and secondary Antibody following blocking with 5% skimmed milk. Chemiluminescent detection was performed using Pierce™ ECL Western Blotting Substrate (Product # 32106).

Immunocytochemistry

Supportive validation

Submitted by

Invitrogen Antibodies (provider)

Main image

Experimental details

For immunofluorescence analysis, HeLa cells were fixed and permeabilized for detection of endogenous Tropomyosin-4 using Anti- TPM-4 Rabbit Polyclonal Antibody (Product # 720311, 2 µg/mL) and labeled with Goat anti-Rabbit IgG (H+L) Superclonal™ Secondary Antibody, Alexa Fluor® 488 conjugate (Product # A27034, 1:2000). Panel a) shows representative cells that were stained for detection and localization of TPM-4 protein (green), Panel b) is stained for nuclei (blue) using SlowFade® Gold Antifade Mountant with DAPI (Product # S36938). Panel c) represents cytoskeletal F-actin staining using Alexa Fluor® 555 Rhodamine Phalloidin (Product # R415, 1:300). Panel d) is a composite image of Panels a, b and c clearly demonstrating cytoskeletal localization of TPM-4. Panel e) represents control cells with no primary antibody to assess background. The images were captured at 60X magnification.
