Validation data
Reference
Comment
Report error
- Product number
- PA5-21000 - Provider product page
- Provider
- Invitrogen Antibodies
- Product name
- ATG101 Polyclonal Antibody
- Antibody type
- Polyclonal
- Antigen
- Synthetic peptide
- Description
- A suggested positive control is human liver tissue lysate. PA5-21000 can be used with blocking peptide PEP-1114.
- Reactivity
- Human, Mouse, Rat
- Host
- Rabbit
- Isotype
- IgG
- Vial size
- 100 µg
- Concentration
- 1 mg/mL
- Storage
- Maintain refrigerated at 2-8°C for up to 3 months. For long term storage store at -20°C
No comments: Submit comment
Supportive validation
- Submitted by
- Invitrogen Antibodies (provider)
- Main image
- Experimental details
- Western blot analysis of human liver tissue lysate using a ATG101 polyclonal antibody (Product # PA5-21000) at (A) 1 and (B) 2 µg/mL.
- Submitted by
- Invitrogen Antibodies (provider)
- Main image
- Experimental details
- Western Blot analysis of ATG101 in human liver tissue lysate with ATG101 Polyclonal Antibody (Product # PA5-21000) at (A) 1 and (B) 2 µg/mL.
- Submitted by
- Invitrogen Antibodies (provider)
- Main image
- Experimental details
- Knockdown of Autophagy-related protein 101 was achieved by transfecting ACHN with Autophagy-related protein 101 specific siRNAs (Silencer® select Product # S34153, S34155). Western blot analysis (Fig. a) was performed using Whole cell extracts from the Autophagy-related protein 101 knockdown cells (lane 3), non-targeting scrambled siRNA transfected cells (lane 2) and untransfected cells (lane 1). The blot was probed with ATG101 Polyclonal Antibody (Product # PA5-21000, 1:1000 dilution ) and Goat anti-Rabbit IgG (H+L) Superclonal™ Recombinant Secondary Antibody, HRP (Product # A27036, 1:20000 dilution). Densitometric analysis of this western blot is shown in histogram (Fig. b). Decrease in signal upon siRNA mediated knock down confirms that antibody is specific to Autophagy-related protein 101.
- Submitted by
- Invitrogen Antibodies (provider)
- Main image
- Experimental details
- Western blot was performed using Anti-ATG101 Polyclonal Antibody (Product # PA5-21000) and a 25 kDa band corresponding to Autophagy-related protein 101 was observed across cell lines and tissue. Whole cell extracts (60 µg lysate) of ACHN (Lane 1), MCF7 (Lane 2), Mouse Thymus (Lane 3) were electrophoresed using NuPAGE™ 12% Bis-Tris Protein Gel (Product # NP0341BOX). Resolved proteins were then transferred onto a nitrocellulose membrane (Product # IB23001) by iBlot® 2 Dry Blotting System (Product # IB21001). The blot was probed with the primary antibody (2 µg/mL) and detected by chemiluminescence with Goat anti-Rabbit IgG (H+L) Superclonal™ Recombinant Secondary Antibody, HRP (Product # A27036,1:20000 dilution using the iBright™ FL1500 Imaging System (Product # A44115). Chemiluminescent detection was performed using SuperSignal™ West Atto Ultimate Sensitivity Substrate (Product # A38556). Non specific bands were observed at ~20 kDa and ~60 kDa.
Supportive validation
- Submitted by
- Invitrogen Antibodies (provider)
- Main image
- Experimental details
- Immunofluorescence of ATG101 in mouse liver tissue with ATG101 Polyclonal Antibody (Product # PA5-21000) at 20 µg/mL.
- Submitted by
- Invitrogen Antibodies (provider)
- Main image
- Experimental details
- Immunofluorescence of ATG101 in mouse liver tissue with ATG101 Polyclonal Antibody (Product # PA5-21000) at 20 µg/mL.
- Submitted by
- Invitrogen Antibodies (provider)
- Main image
- Experimental details
- Immunohistochemistry of ATG101 in mouse liver with ATG101 Polyclonal Antibody (Product # PA5-21000) at 5 µg/mL.
