- Product number
- MA3-901 - Provider product page
- Provider
- Invitrogen Antibodies
- Product name
- CNGA3 Monoclonal Antibody (CNC 9C1)
- Antibody type
- Monoclonal
- Antigen
- Other
- Description
- MA3-901 detects CNG channel from human, mouse and rat samples. MA3-901 has been successfully used in Western blotting and immunohistochemistry procedures. By Western blot MA3-901 detects a band representing CNG channel. MA3-901 is specific to the a2 subunit of the CNG channel. The MA3-901 immunogen is a MBP-fusion protein of the C-terminal region of the rat a2 subunit (amino acids K581-D670)
- Reactivity
- Human, Mouse, Rat
- Host
- Mouse
- Isotype
- IgG
- Antibody clone number
- CNC 9C1
- Vial size
- 100 µL
- Concentration
- Conc. Not Determined
- Storage
- -20° C, Avoid Freeze/Thaw Cycles
Submitted references A cGMP-signaling pathway in a subset of olfactory sensory neurons.
Meyer MR, Angele A, Kremmer E, Kaupp UB, Muller F
Proceedings of the National Academy of Sciences of the United States of America 2000 Sep 12;97(19):10595-600
Proceedings of the National Academy of Sciences of the United States of America 2000 Sep 12;97(19):10595-600
No comments: Submit comment
Supportive validation
- Submitted by
- Invitrogen Antibodies (provider)
- Main image
- Experimental details
- Immunofluorescent analysis using CNGA3 Monoclonal Antibody (CNC 9C1) (Product # MA3-901) shows CNGA3 staining in B-3 Cells (green). F-Actin staining with Phalloidin (red) and nuclei with DAPI (blue) is shown. Cells were grown on chamber slides and fixed with formaldehyde prior to staining. Cells were probed without (control) or with an antibody recognizing CNGA3 (Product # MA3-901) at a dilution of 1:20 over night at 4°C, washed with PBS and incubated with a DyLight-488 conjugated secondary antibody (Product # 35503, Goat Anti-Mouse). Images were taken at 60X magnification.
- Submitted by
- Invitrogen Antibodies (provider)
- Main image
- Experimental details
- Immunofluorescent analysis using CNGA3 Monoclonal Antibody (CNC 9C1) (Product # MA3-901) shows CNGA3 staining in Hela Cells (green). F-Actin staining with Phalloidin (red) and nuclei with DAPI (blue) is shown. Cells were grown on chamber slides and fixed with formaldehyde prior to staining. Cells were probed without (control) or with an antibody recognizing CNGA3 (Product # MA3-901) at a dilution of 1:20 over night at 4°C, washed with PBS and incubated with a DyLight-488 conjugated secondary antibody (Product # 35503, Goat Anti-Mouse). Images were taken at 60X magnification.
- Submitted by
- Invitrogen Antibodies (provider)
- Main image
- Experimental details
- Immunofluorescent analysis using CNGA3 Monoclonal Antibody (CNC 9C1) (Product # MA3-901) shows CNGA3 staining in U251 Cells (green). F-Actin staining with Phalloidin (red) and nuclei with DAPI (blue) is shown. Cells were grown on chamber slides and fixed with formaldehyde prior to staining. Cells were probed without (control) or with an antibody recognizing CNGA3 (Product # MA3-901) at a dilution of 1:20 over night at 4°C, washed with PBS and incubated with a DyLight-488 conjugated secondary antibody (Product # 35503, Goat Anti-Mouse). Images were taken at 60X magnification.
