MA5-14924

antibody from Invitrogen Antibodies

Targeting: LYN JTK8

Western blot

Immunoprecipitation

Antibody data

Submit

Validation data

Product number: MA5-14924 - Provider product page
Provider: Invitrogen Antibodies
Product name: Lyn Monoclonal Antibody (R.677.10)
Antibody type: Monoclonal
Antigen: Synthetic peptide
Description: It is not recommended to aliquot this antibody. This antibody is not cross-reactive with any other Src-family members.
Reactivity: Human, Mouse, Rat
Host: Rabbit
Isotype: IgG
Antibody clone number: R.677.10
Vial size: 100 μL
Concentration: 16.7 μg/mL
Storage: -20°C

LYN protein structure - MA5-14924 shown in red.

Supportive validation

Submitted by: Invitrogen Antibodies (provider)
Main image
Experimental details: Immunofluorescence analysis of Tyrosine-protein kinase Lyn was performed using 70% confluent log phase A431 cells. The cells were fixed with 4% paraformaldehyde for 10 minutes, permeabilized with 0.1% Triton™ X-100 for 15 minutes, and blocked with 2% BSA for 45 minutes at room temperature. The cells were labeled with Lyn Monoclonal Antibody (R.677.10) (Product # MA5-14924) at 5 µg/mL in 0.1% BSA, incubated at 4 degree celsius overnight and then labeled with Donkey anti-Rabbit IgG (H+L) Highly Cross-Adsorbed Secondary Antibody, Alexa Fluor Plus 488 (Product # A32790), (1:2000), for 45 minutes at room temperature (Panel a: Green). Nuclei (Panel b:Blue) were stained with ProLong™ Diamond Antifade Mountant with DAPI (Product # P36962). F-actin (Panel c: Red) was stained with Rhodamine Phalloidin (Product # R415, 1:300). Panel d represents the merged image showing Cytoplasmic localization. Panel e represents control cells with no primary antibody to assess background. The images were captured at 40X magnification.

Supportive validation

Submitted by: Invitrogen Antibodies (provider)
Main image
Experimental details: Immunofluorescence analysis of Tyrosine-protein kinase Lyn was performed using 70% confluent log phase A431 cells. The cells were fixed with 4% paraformaldehyde for 10 minutes, permeabilized with 0.1% Triton™ X-100 for 15 minutes, and blocked with 2% BSA for 45 minutes at room temperature. The cells were labeled with Lyn Monoclonal Antibody (R.677.10) (Product # MA5-14924) at 5 µg/mL in 0.1% BSA, incubated at 4 degree celsius overnight and then labeled with Donkey anti-Rabbit IgG (H+L) Highly Cross-Adsorbed Secondary Antibody, Alexa Fluor Plus 488 (Product # A32790), (1:2000), for 45 minutes at room temperature (Panel a: Green). Nuclei (Panel b:Blue) were stained with ProLong™ Diamond Antifade Mountant with DAPI (Product # P36962). F-actin (Panel c: Red) was stained with Rhodamine Phalloidin (Product # R415, 1:300). Panel d represents the merged image showing Cytoplasmic localization. Panel e represents control cells with no primary antibody to assess background. The images were captured at 40X magnification.
